High configuration Charmhigh CHM-751 Advanced 6 heads SMT pick and place machine
Good for medium SMT assembly line, for PCBA manufacturing
6 Heads 50 Feeders, Auto Rails, Double grinding screw, Auto Nozzle changer, PCB stand support, Japan PISCO vacuum generator, servo motor
Higher precision CPK≥1.0 (X Y), Mounting speed 17000cph (optimal) , IPC9850: 13400CPH
CHM-751 Machine Features
1. Thermal Compensation
2. Support CPK test, 0201 perfect mounting
3. Built-in Vacuum Pump
4. Automatic nozzle change (19 sets nozzle library)
5. PCB Support Device, good for bigger PCB
6. 6 head + 50 Yamaha feeder stacks + 9 cameras
7. Double Y axis with double servo motors
8. 6 heads picking at the same time
9. Dual mark cameras, good for bigger PCB
10......
For more machine features, please consult our account manager
Other information for CHM-751 Pick and place robot:
1. Max PCB area: 400mm(L)*350mm(W)
2. Component: 0201, 0402-5050, SOP, QFN,BGA,PLCC... etc.
3. Highlight: 0201, auto nozzle change, double grinding screw, updated smart software, PCB support, servor motors, passed CPK inspection
4. Delivery: by air / Sea (FOB, CIF, DDU,DDP...etc) or EXW, you can arrange pick up from our factory directly.
5. Payment method: T/T; W/U
6. Lead-time: 5-7 days
7. Packing: export wooden box
CHM-751 is a high-confuguration 6 heads SMT pick and palce machine from Charmhigh, It is a perfect model which can meet all customers' demand. Below is the medium SMT production line: 3250 Solder paste printer, PCB loader, CHM-751, SMT conveyor, 830 reflow oven
Warranty:
The complete machine has a warranty period of 1 year from the time of purchase and lifelong service
support as well as a long term factory price supply.
We provide online Q/A and troubleshooting support and technical advice service.
Provide one to one after-sale service. Each machine 100% test well before ship out.
Tech support:
Kimi Mob: 0086 135 106 75756
Skype: kimiliu89
E-mail: kimi@charmhigh-tech.com
Youtube video link of Charmhigh: https://www.youtube.com/@KimiLiuCharmhigh/videos
Charmhigh, famouse manuafacturer in China supply directly, quality assurance.
CHM-751 Specifications | |
Dimensions | 1280mm(L)×1260mm(W)×1500mm(H) |
Weight | 670kg |
Power Supply | AC220V (50Hz, single phase), 2.8kW |
Air Supply | 0.5MPa ~0.7MPa |
Vacuum Generation | Built-in vacuum pump |
Mounting Head Quantity | 6 heads |
Mounting Speed | 18400CPH (optimal); IPC9850: 13400CPH |
Mounting Accuracy | (XY)±0.05mm; CPK≥1.0 |
Component Height | 12mm |
Component Type | 0201/0402/0603~5050/SOT/SOP/QFP/QFN/BGA, etc. (resistor/capacitor/diode/triode/LED/IC, etc.) |
PCB Thickness | 0.6mm~3.5mm |
PCB Size | 400mm(L)×350mm(W) |
PCB Conveying | 3-section-rail automatic conveying, PCB support |
Nozzle Change | Automatic nozzle change (19-hole nozzle library) |
Control System | Built-in industrial computer (Windows 7) equipped with monitor, keyboard, and mouse |
Drive System | X&Y axis driven by servo motors (Y axis by double motors); adopting flexible S-curve acceleration and deceleration |
Transmission System | Ground Ball screw + linear guide (Y axis with double screws) |
Feeding System | 50 Yamaha 8mm standard pneumatic/electric feeder stacks (also suitable for IC tray and stick feeder) |
Vision System | Snapshot camera×6 (component size applicable: 16mm×16mm); IC camera×1 (component size applicable: 36mm×36mm); Mark camera×2 |
